TL;DR:

The github repo with all scripts are here.

Because of specific requirements, reasons, or preferences, some customers need to self-manage a Microsoft AD directory on-premises or in the cloud.

AWS offers options to have their fully managed Microsoft Windows file servers (Amazon FSx for Windows File Server) join a self-managed Microsoft Active Directory.

In this post, I will provide an example of launching an FSx for Windows File Server and joining a self-managed domain using Terraform.

This article won’t go into details on the following items as they are presumed to already be created.

Requirements:



  • self-managed Microsoft AD directory
  • the fully qualified, distinguished name (FQDN) of the organisational unit (OU) within your self-managed AD directory that the Windows File Server instance will join; and
  • valid DNS servers and networking configuration (VPC/Subnets) that allows traffic from the file system to the domain controller.

In addition, I recommend to go through the steps “Validating your Active Directory configuration” from AWS Documentation at the following link to validate self-managed AD configuration before starting creation of the FSx filesystem:

On the file _variables.tf, we will provide the details for the self-managed AD, including IPs, DNS Name, Organisational Unit, and Domain Username and Password:

_variables.tf

variable "ad_directory_name" {
 type    = string
 default = "example.com"
}

variable "ad_directory_ip1" {
 type    = string
 default = "XXX.XXX.XXX.XXX"
}

variable "ad_directory_ip2" {
 type    = string
 default = "XXX.XXX.XXX.XXX"
}

variable "fsx_name" {
 type    = string
 default = "fsxblogpost"
}

variable "domain_ou_path" {
 type    = string
 default = "OU=Domain Controllers,DC=example,DC=com"
}

variable "domain_fsx_username" {
 type    = string
 default = "fsx"
}

variable "domain_fsx_password" {
 type    = string
 default = "placeholder"
}

variable "fsx_deployment_type" {
 type    = string
 default = "SINGLE_AZ_1"
}

variable "fsx_subnet_ids" {
 type    = list(string)
 default = ["subnet-XXXXXXXXXXXX"]
}

variable "vpc_id" {
 type    = string
 default = "vpc-XXXXXXXXXXXX"
}


variable "fsx_deployment_type" {
 type    = string
 default = "SINGLE_AZ_1"
}

variable "fsx_subnet_ids" {
 type    = list(string)
 default = ["subnet-XXXXXXXXXXXX"]
}

variable "vpc_id" {
 type    = string
 default = "vpc-XXXXXXXXXXXX"
}

The file fsx.tf is where we will effectively create FSx filesystem, and also KMS encryption key and KMS Key policy. The KMS key is optional, however I strongly recommend having the filesystem encrypted.

fsx.tf


data "aws_iam_policy_document" "fsx_kms" {
 statement {
   sid       = "Allow FSx to encrypt storage"
   actions   = ["kms:GenerateDataKey"]
   resources = ["*"]
   principals {
     type        = "Service"
     identifiers = ["fsx.amazonaws.com"]
   }
 }
 statement {
   sid       = "Allow account to manage key"
   actions   = ["kms:*"]
   resources = ["arn:aws:kms:${data.aws_region.current.name}:${data.aws_caller_identity.current.account_id}:key/*"]
   principals {
     type        = "AWS"
     identifiers = ["arn:aws:iam::${data.aws_caller_identity.current.account_id}:root"]
   }
 }
}

resource "aws_kms_key" "fsx" {
 description             = "FSx Key"
 deletion_window_in_days = 7
 policy                  = data.aws_iam_policy_document.fsx_kms.json
}

resource "aws_fsx_windows_file_system" "fsx" {
 kms_key_id          = aws_kms_key.fsx.arn
 storage_capacity    = 100
 subnet_ids          = var.fsx_subnet_ids
 throughput_capacity = 32
 security_group_ids  = [aws_security_group.fsx_sg.id]
 deployment_type     = var.fsx_deployment_type

 self_managed_active_directory {
   dns_ips                                = [var.ad_directory_ip1, var.ad_directory_ip2]
   domain_name                            = var.ad_directory_name
   username                               = var.domain_fsx_username
   password                               = var.domain_fsx_password
   organizational_unit_distinguished_name = var.domain_ou_path
 }
}

resource "aws_security_group" "fsx_sg" {
 name        = "${var.fsx_name}-fsx-sg"
 description = "SG for FSx"
 vpc_id      = data.aws_vpc.selected.id

 tags = {
   Name = "${var.fsx_name}-fsx-sg"
 }
}

resource "aws_security_group_rule" "fsx_default_egress" {
 description       = "Traffic to internet"
 type              = "egress"
 from_port         = 0
 to_port           = 0
 protocol          = "-1"
 security_group_id = aws_security_group.fsx_sg.id
 cidr_blocks       = ["0.0.0.0/0"]
}

resource "aws_security_group_rule" "fsx_access_from_vpc" {
 type              = "ingress"data "aws_iam_policy_document" "fsx_kms" {
  statement {
    sid       = "Allow FSx to encrypt storage"
    actions   = ["kms:GenerateDataKey"]
    resources = ["*"]
    principals {
      type        = "Service"
      identifiers = ["fsx.amazonaws.com"]
    }
  }
  statement {
    sid       = "Allow account to manage key"
    actions   = ["kms:*"]
    resources = ["arn:aws:kms:${data.aws_region.current.name}:${data.aws_caller_identity.current.account_id}:key/*"]
    principals {
      type        = "AWS"
      identifiers = ["arn:aws:iam::${data.aws_caller_identity.current.account_id}:root"]
    }
  }
}

resource "aws_kms_key" "fsx" {
  description             = "FSx Key"
  deletion_window_in_days = 7
  policy                  = data.aws_iam_policy_document.fsx_kms.json
}

resource "aws_fsx_windows_file_system" "fsx" {
  kms_key_id          = aws_kms_key.fsx.arn
  storage_capacity    = 100
  subnet_ids          = var.fsx_subnet_ids
  throughput_capacity = 32
  security_group_ids  = [aws_security_group.fsx_sg.id]
  deployment_type     = var.fsx_deployment_type

  self_managed_active_directory {
    dns_ips                                = [var.ad_directory_ip1, var.ad_directory_ip2]
    domain_name                            = var.ad_directory_name
    username                               = var.domain_fsx_username
    password                               = var.domain_fsx_password
    organizational_unit_distinguished_name = var.domain_ou_path
  }
}

resource "aws_security_group" "fsx_sg" {
  name        = "${var.fsx_name}-fsx-sg"
  description = "SG for FSx"
  vpc_id      = data.aws_vpc.selected.id

  tags = {
    Name = "-${var.fsx_name}-fsx-sg"
  }
}

resource "aws_security_group_rule" "fsx_default_egress" {
  description       = "Traffic to internet"
  type              = "egress"
  from_port         = 0
  to_port           = 0
  protocol          = "-1"
  security_group_id = aws_security_group.fsx_sg.id
  cidr_blocks       = ["0.0.0.0/0"]
}

resource "aws_security_group_rule" "fsx_access_from_vpc" {
  type              = "ingress"
  from_port         = 0
  to_port           = 0
  protocol          = "-1"
  security_group_id = aws_security_group.fsx_sg.id
  cidr_blocks       = [data.aws_vpc.selected.cidr_block]
}

 from_port         = 0
 to_port           = 0
 protocol          = "-1"
 security_group_id = aws_security_group.fsx_sg.id
 cidr_blocks       = [data.aws_vpc.selected.cidr_block]
}

Once you apply the scripts on Terraform, it should take around 15 minutes for the resources to be created:


aws_fsx_windows_file_system.fsx: Creation complete after 15m54s [id=fs-05701e8e6ad3fbe24]

Apply complete! Resources: 5 added, 0 changed, 0 destroyed.

You should see the FSx created and in Available state on AWS Console, which means FSx was able to join the self-managed domain:

Amazon FSx created and in available state on AWS console

Conclusion



I hope the instructions and terraform scripts provided can make your life easier when launching FSx for Windows File Server and joining a self-managed domain using Terraform.

When recently working on a project, I noticed there weren’t many examples online, so I decided to write this blog post to help others.

I would encourage you to open an issue or feature request on the github repo in case you need any additional help when using the scripts.
